420
STARTING AND OPERATING
3. When user recognition is completed, the Hello screen appears on the combination meter display( color LCD).
At this time, climate control settings, combination meter display( color LCD) basic screen, center information display basic screen, and customization settings all change based on the user information.
Repeat Facial Scan s07bp0404
NOTE
. When a center information display operation switch is pressed, the user recognition screen is canceled, however user recognition continues.
. If user recognition fails, perform recognition again following the instructions, refer to“ Repeat Facial Scan” FP420.
. User recognition is not performed while driving.
. When the select lever is not in the“ P” position, the seat position will not change even when user recognition is completed.
. If the seat position or outside mirror angle are in motion at the time when user recognition is completed, then it is not possible to retrieve the seat position, outside mirror angle, or reverse tilt-down outside mirror angle.
. If any of the following operations is performed while retrieving of the seat position or outside mirror angle, retrieving of the seat position and outside mirror angle is canceled.
– The power seat adjustment switch
was operated. – The outside mirror adjustment
switch was operated. – The“ SET” button was pressed. – The“ 1” or“ 2” button was pressed. – The select lever was moved to a
position other than“ P” position.
Camera
S _ 703306-W
When there is an object blocking the camera, user recognition may not be possible and“ User recognition stopped.” may be displayed. Remove the obstacle and follow the reference procedure to perform user recognition again.
1. Touch( HOME). 2.?( Settings) 3.?“ Car” 4.?“ Driver Monitoring System” 5.?“ Repeat Facial Scan” 6.?“ OK”
S _ 307591-W
7. While seated in the driver’ s seat, face forward and wait for a few moments. When the scan is completed, the completion screen is displayed on the center information display.
