394
STARTING AND OPERATING
This display appears when the detectability of the radar sensors is reduced. Once the condition is corrected, the system will recover from the temporary stop condition and the indicator will disappear.
BSD / RCTA OFF indicator
If the indicator remains displayed for a prolonged time, have the system inspected at a SUBARU dealer.
BSD / RCTA WARNING INDICA- TOR s07bm04
S _ 703291-W
BSD / RCTA malfunction message At first, this message will appear Then this message will appear BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system. Contact a SUBARU dealer and have the system inspected.
TO TURN ON / OFF THE BSD / RCTA s07bm09
To turn the BSD / RCTA system on and off, operate the center information display. Refer to“ Settings icon( Car settings)” FP231( 11.6-inch display models).
S _ 703180-W
When the BSD / RCTA system is turned OFF, the BSD / RCTA OFF indicator on the combination meter display( color LCD) will illuminate.
NOTE
. In the following cases, turn off the BSD / RCTA system. The system may not operate properly due to blocked radar waves.
– When towing a load – When a bicycle carrier or other item
is fitted to the rear of the vehicle – When using a chassis dynamometer or free roller device, etc. – When running the engine and
making the wheels rotate while lifting up the vehicle
. If the ignition switch is turned to the“ LOCK”/“ OFF” position, the last known status of the system is maintained. For example, if the ignition switch is turned to the“ LOCK”/“ OFF” position with the BSD / RCTA deactivated, the BSD / RCTA remains deactivated the next time the ignition switch is turned to the“ ON” position.
