INSTRUMENTS AND CONTROLS 209
HOW TO CHANGE THE SCREEN SETTINGS s03bw05
Set and adjust the brightness and contrast of the center information display.
Brightness / Contrast
1. Press( HOME). 2. Touch( Settings) 3.?“ General” 4.?“ Display” 5.?“ Brightness / Contrast” s03bw0501
Lower main screen:
If this screen changes to the climate control screen, refer to“ Dual 7.0-Inch Display Models” FP278.
Valet mode icon s03bw0401
For details, refer to“ Valet Mode” FP237
Display Off s03bw0402
Activation of the display off mode:
Touch“ Display Off”.
3
S _ 307796-W
6. Drag to adjust the brightness and contrast.
Touch“ Default” to revert to the factory setting.
NOTE
“ Brightness” can only be adjusted when“ Brightness Dial” is off. Refer to“ Settings icon( General settings)” FP210.
SHORTCUT ICONS
Upper main screen:
For details about the following menu, refer to the separate audio Owner’ s Manual.
. Radio. Media. Phone. Apps. Add to Shortcut
s03bw04
S _ 307607-W
Deactivation of the display off mode:
Press and hold the volume knob to turn the screen back on.
S _ 307608-W
– CONTINUED –
