INSTRUMENTS AND CONTROLS 199
WARNING SCREEN
Example of warning s03bn05
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption.
The ECO gauge indicates the current fuel efficiency as shown in the following chart.
Displayed unit
Needle position
“+” side“ −” side MPG Better Poorer l / 100km Poorer Better
3
S _ 307548-W
If there is a warning message or a maintenance notification, it will appear on combination meter display( color LCD). Take the appropriate actions based on the messages indicated.
METER INFORMATION SCREEN s03bn12
This screen informs the driver of various information.
The meter information screen can be changed. For details, refer to the following sections.
–“ Settings icon( General settings)” FP210( dual 7.0-inch display models)
–“ Settings icon( General settings)” FP227( 11.6-inch display models)
ECO gauge s03bn1201
S _ 307549-W
NOTE
. The ECO gauge shows only an approximate indication.
. After resetting the trip meter, the average rate of fuel consumption is not shown until driving 0.6 miles( 1 km). Until that time, the ECO gauge does not operate.
Clock and temperature s03bn1202
S _ 307550-W
This screen displays the clock and outside temperature.
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display. For details, refer to“ Setting 12-Hour Display / 24-Hour Display” FP236.
. The outside temperature indicator shows the temperature in the area around the sensor. However, the temperature may not be indicated correctly or the update may be de-
– CONTINUED –
