About EyeSight
( 25 )
( 26 )
( 27 )
( 28 )
( 29 )
( 30 )
Driver Monitoring System operation indicator light ( green ) ( if equipped ) This indicator light illuminates while Driver Monitoring System operates . � Refer to the vehicle Owner ’ s Manual for details . Driver Monitoring System warning light ( yellow ) ( if equipped ) This warning light illuminates when a malfunction occurs in the Driver Monitoring System . � Refer to the vehicle Owner ’ s Manual for details . Driver Monitoring System OFF indicator light ( if equipped ) This indicator light illuminates when Driver Monitoring System is off . � Refer to the vehicle Owner ’ s Manual for details . Driver Monitoring System temporary stop indicator light ( if equipped ) This indicator light illuminates when the Driver Monitoring System is temporarily stopped . � Refer to the vehicle Owner ’ s Manual for details . X-MODE indicator This indicator illuminates when the X-MODE is on . � Refer to the vehicle Owner ’ s Manual for details .
Lane Departure Warning OFF indicator light This indicator light illuminates when the ignition switch is turned to the ON position , and then turns off several seconds after the engine starts .
� Pages 149 and 153
Pre-Collision Braking System OFF indicator light
• This indicator light illuminates when the ignition switch is turned to the ON position , and then turns off several seconds after the engine starts .
• It illuminates when Pre-Collision Braking System and Pre-Collision Throttle Management are off .
� Pages 62 and 144
23
