370
STARTING AND OPERATING
. The actual position may be different from the indication of the help lines.
. Differences may occur due to the number of passengers or the loaded cargo.
. When the vehicle is on a slope or inclined against the road, the indication is different from the actual position.
When there is a downward slope at the back:
NOTE
When“ Steering Angle Lines” is off, the dynamic guidelines will disappear on the center information display. To turn the dynamic guidelines on and off, refer to“ Settings icon( General settings)” FP222.
Difference between screen image and actual road s07br0301
The distance markers show the distance for a level road when the vehicle is not loaded. It may be different from the actual distance depending on the loading conditions or road conditions.
When there is an upward slope at the back:
3 ft( 1 m)
S _ 703282-MW
The distance on the screen looks nearer than the actual distance.
NOTE
When cargo is loaded, the rear view distance on the screen looks farther than the actual distance as in an upward slope.
Feature of distance marker s07br0302
3 ft( 1 m) line 10 ft( 3 m) line
S _ 703283-W
3 ft( 1 m)
S _ 703281-MW
The distance marker shows the distance on the road. If there is a car or another object close behind, distance cannot be correctly displayed.
The distance on the screen looks farther than the actual distance.
