360
BSD / RCTA
! Lane Change Assist ( LCA )
S07BM010101
! Rear Cross Traffic Alert ( RCTA )
S07BM0103
! Limitations of the detectability of RCTA
S07BM010301
Since the detectability of RCTA is limited , the RCTA may not operate properly in angled parking .
1 Operating range
The system warns the driver of dangers as follows .
. If the system detects a vehicle approaching at a high speed in the neighboring lanes , the BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ) will illuminate .
. If the driver operates the turn signal lever in the direction which the BSD / RCTA approach indicator light is illuminating , the corresponding BSD / RCTA approach indicator light will flash .
1 Operating range
The system notifies the driver of another vehicle approaching from either side when driving in reverse . This feature helps the driver check the rear and side areas of the vehicle when moving backward .
If the system detects a vehicle approaching from either side while moving backward , it warns the driver of dangers in the following way .
. The BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ) flashes .
. A warning buzzer sounds .
. An icon appears on the rear view camera screen ( audio / navigation monitor )
Example 1 1 The detection range of the radar sensors 2 Area out of detection range of the radar sensors
A Vehicle that may not be detected . B Parked vehicle
WARNING
An approaching vehicle ( A ) may not be detected because the detection range is limited by the parked vehicle ( B ). Always be sure to check the surroundings when reversing the
