& System features
S07BM01
BSD / RCTA consists of the following functions .
. To detect a vehicle in a blind spot on an adjacent lane or a vehicle approaching at high speeds ( Blind Spot Detection ).
. To detect a vehicle approaching from the right or left while reversing the vehicle ( Rear Cross Traffic Alert ).
The system uses radar sensors for the above functions .
NOTE
The BSD / RCTA radar sensor has been certified by the radio wave related laws of the U . S . and Canada . When driving in other countries , certification of the country where the vehicle is driven must be obtained . For certification in the U . S . and Canada , refer to “ Certification for the BSD / RCTA ” FP366 .
|
1 Operating range
The system warns the driver of dangers as follows .
. If the system detects a vehicle in the blind spot , the BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ) will illuminate .
|
BSD / RCTA approach indicator light
. If the driver operates the turn signal lever in the direction which the BSD / RCTA approach indicator light is illuminating , the corresponding BSD / RCTA approach indicator light will flash .
|
Starting and operating |
|||||
– CONTINUED – |
