Continuously variable transmission 327 |
||||||||
|
CAUTION
Do not place or hang anything on the shift paddles . Doing so may result in accidental gear shifting .
|
safe location and let the engine idle until the warning light turns off .
& Selection of “ L ” ( if equipped )
S07BG03
|
“ L ” is for using engine braking when going down a hill , etc . To select this mode , move the select lever from the “ D ” position to the “ L ” position . |
||||||
|
NOTE
Please read the following points carefully and bear them in mind when using the manual mode .
. If you attempt to shift down when the engine speed is too high , i . e ., when a downshift would push the tachometer needle beyond the red zone , beeps will be emitted to warn you that the downshift is not possible .
. If you attempt to shift up when the vehicle speed is too low , the transmission will not respond .
. You can perform a skip-shift ( for example , from 4th to 2nd ) by operating the shift paddle twice in rapid succession .
. The transmission automatically selects 1st gear when the vehicle stops moving .
. If the temperature of the transmission fluid becomes too high , the “ AT OIL TEMP ” warning light on the combination meter will illuminate . Immediately stop the vehicle in a
|
Type A
Type B
|
When selected , the indicator “ L ” will illuminate on the combination meter .
To deselect “ L ”, move the select lever to the “ D ” position .
& Shift lock function
S07BG04
The shift lock function helps prevent the improper operation of the select lever .
. The select lever cannot be operated unless the ignition switch is turned to the “ ON ” position and the brake pedal is depressed .
. The select lever cannot be moved from the “ P ” position to any other position
|
Starting and operating |
|||||
– CONTINUED – |
