264
Climate control panel
& Type C
S04AG03
1 Temperature control dial ( Refer to “ Automatic climate control operation ” FP265 and / or “ Temperature control ” FP269 .)
2 AUTO button ( Refer to “ Automatic climate control operation ” FP265 .)
3 Air conditioner button ( Refer to “ Air conditioner control ” FP269 .)
4 Air inlet selection button ( Refer to “ Air inlet selection ” FP270 .)
5 MAX A / C button ( Refer to “ MAX A / C mode ( for type B and C )” FP269 .)
6 Defroster button ( Refer to “ Defrosting ” FP271 .)
7 Rear window defogger button and outside mirror defogger button ( Refer to “ Defogger and deicer ” FP254 .)
8 Airflow mode selection dial ( Refer to “ Airflow mode selection ” FP267 .)
9 Fan speed control dial ( Refer to “ Fan speed control ” FP269 .)
10 ON / OFF button ( Refer to “ Automatic climate control operation ” FP265 .)
NOTE
The climate control screen is displayed on the multi-function display ( color LCD ). Refer to “ Climate control screen ” FP208 .
