Combination meter display ( color LCD ) 199 |
|||||||||
|
& Menu screens
S03BN07
Pull and hold the “ / SET ” switch to enter the menu screens when all of the following conditions are satisfied .
. The menu screen entering screen is selected .
. The “ ” information reminder is off .
NOTE
. While driving , the setting items available on the combination meter display ( color LCD ) are limited .
. For function settings and adjustments on the combination meter display , refer to “ Function settings ” FP24 .
By operating the “ ” or “ ” switch on the steering wheel , you can select the menu . Pull the “ / SET ” switch to enter the selected menu .
NOTE
If you enter the “ Go Back ” menu , the system will return to the previous screen .
|
! Screen Settings
S03BN0701
After entering the “ Screen Settings ” menu , select one of the following menus .
|
! Welcome Screen
S03BN070101
The welcome screen can be activated or deactivated .
! Good-bye Screen
S03BN070106
The good-bye screen can be activated or deactivated .
! Gauge Initial Movement
S03BN070102
The movement of the meter needles and gauge needles that occurs when the ignition switch is turned to the “ ON ” position can be activated or deactivated .
! Units
S03BN070108
Changes the units displayed in the combination meter display ( color LCD ), the multifunction display ( black and white ) and the multi-function display ( color LCD ).
! Tire Pressure Units ( U . S . -spec . models )
S03BN070109
Changes the units displayed in the Tire Pressure Monitoring system .
! Languages
S03BN070103
Changes the language displayed in the combination meter display ( color LCD ) and the multi-function display ( color LCD ).
|
! Warning Volume
S03BN0713
Sets the EyeSight warning volume , the BSD / RCTA warning volume and the RAB warning volume .
! Rear Seat Reminder
S03BN0715
The rear seat reminder can be activated or deactivated .
! EyeSight
S03BN0702
NOTE
For details about how to use the EyeSight system , refer to the Owner ’ s Manual supplement for the EyeSight system .
! RAB ( if equipped )
S03BN0712
! Sonar Audible Alarm
S03BN071204
When the Reverse Automatic Braking ( RAB ) system is in operation , the warning sound to notify that an obstacle is detected in the rear can be activated or deactivated .
NOTE
For models with Reverse Automatic Braking ( RAB ) system , refer to “ Reverse Automatic Braking ( RAB ) system ” FP368 .
! Vehicle Setting
S03BN0708
After entering the “ Vehicle Setting ” menu , select one of the following menus .
|
Instruments and controls |
|||||
– CONTINUED – |
