198
Combination meter display ( color LCD )
Auto Start Stop screen :
: The total amount of time that the engine was stopped by means of the Auto Start Stop system
: The total amount of fuel saved due to the engine being stopped by the Auto Start Stop system
The indicated values are calculated from the most recent reset of the currently displayed trip meter to the current time . The indication ranges are as follows .
. Total amount of time : from 00 ’ 00 @ to 9999h59 ’ 59 @
. Total amount of fuel saved : from 0 ml to 9999.999 L
NOTE
. When the trip meter is reset , the corresponding accumulated time and the amount of fuel saving are
also reset .
. The time spent with the engine stopped by means of the Auto Start Stop system is also added to the journey time .
TPMS screen ( U . S . -spec . models ):
This screen displays each tire pressure .
When a tire is deflated , the deflated tire and the tire pressure will be displayed on the screen in yellow .
NOTE
. The tire pressure values are displayed several minutes after driving .
. The tire pressure units can be set . For details about setting the units , refer to “ Tire Pressure Units ( U . S . - spec . models )” FP199 .
. Once the tire pressure monitoring system detects the low tire pressure , the tire pressure values will display in yellow until the system detects the normal tire pressure .
. Immediately adjust the tire pressure when the warning light illuminates . When the tire pressure monitoring system detects the adjusted tire pressure , the warning light will turn off and the tire pressure values will turn to white .
. For information about the specified value of the air pressure , refer to “ Tires ” FP504 .
Menu screen entering screen :
While this screen is selected , pull and hold the “ / SET ” switch to enter the menu screen .
