194
Combination meter display ( color LCD )
4 |
Telltale screen ( Refer to “ Telltale screen ” |
FP195 .) |
5 |
Select lever / gear position indicator ( Refer |
to “ Select lever / gear position indicator |
” FP189 .) |
6 |
X-MODE indicator ( if equipped ) ( Refer to |
“ X-MODE indicator light ” FP191 .) |
SI-DRIVE indicator ( Refer to “ SI-DRIVE |
indicator light ” FP189 .) |
7 |
Odometer |
( Refer |
to |
“ Odometer ” |
FP165 .)/ Double trip meter ( Refer to |
“ Double trip meter ” FP165 .) |
8 |
Fuel gauge ( Refer to “ Fuel gauge ” |
FP166 .) |
A : |
Deactivating the EyeSight system |
B : |
Activating the EyeSight system |
& Basic operation
Control switch 1 ( Up ) 2 / SET ( Enter ) 3 ( Down )
S03BN01
By operating “ ” or “ ” of the control switch , the screens and selection items can be switched . When the “ / SET ” switch is pulled toward you , the item can be selected and set .
If there are some useful messages , such as vehicle information , warning information , etc ., they will interrupt the current screen , and appear on the display accompanied by a beep . If such a screen is displayed , take proper action according to the message shown on the screen .
The warning screen will return to the original screen after a few seconds . While the “ ” information reminder is shown on the display , it may be possible to display the warning screen again . To recall the message marked with “ ” on the display , pull the “ / SET ” switch on the steering wheel toward you .
NOTE
When the multi-function display ( color LCD ) is set to the setting screen , the combination meter display ( color LCD ) cannot be controlled pressing on the “ ”, “ ” and “ / SET ” on the control switch .
& Welcome screen ( opening animation ) and Good-bye ( ending animation ) screen
S03BN08
When the driver ’ s door is opened and closed after unlocking the door , the welcome screen ( opening animation ) will appear on the combination meter display ( color LCD ) for approximately 20 seconds .
When the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the combination meter display ( color LCD ) gradually turns off by showing good-bye screen ( ending animation ).
