384
Driver Monitoring System
! When a user is not recognized
S07BP0402
In the following case , user recognition may not be possible and “ User recognition stopped ” may be displayed .
. There is an object blocking the camera .
Remove the obstacle and follow the reference procedure to perform user recognition again .
Refer to “ Repeat facial scan ” FP214 .
1 Camera
NOTE
. User recognition may not be possible when there is dirt or fingerprints on the user recognition camera . To clean , either wipe using a soft cloth or else wipe gently using a moistened cloth that has been thoroughly wrung out .
. When the synchronized user function is turned OFF , manual repeat facial scan is not possible .
& Registering and deleting a user
S07BP05
Users can be registered in the Driver Monitoring System , and registered users can be deleted . For the user registration and delete procedures , refer to “ Driver Monitoring System settings ” FP214 .
NOTE
. When the Driver Monitoring System OFF indicator , Driver Monitoring System temporary stop indicator , or Driver Monitoring System warning is illuminated , the following items cannot be selected . – Register User – Delete User – Delete All Users
. User information can also be deleted by resetting the multi-function display to the factory default settings . When the settings are reset to the factory default settings , all user information is deleted . The settings cannot be reset to the factory default settings when the Driver Monitoring System is OFF .
& Registering and deleting driver position personalization
S07BP06
At the time when a user is registered , the seat position , outside mirror angle , and reverse tilt-down outside mirror angle are registered at the same time . To change the setting for the seat position , outside mirror angle , or reverse tilt-down outside mirror angle , refer to “ Driver Monitoring System settings ” FP214 .
NOTE
. Start the user registration after adjusting the seat position , outside mirror angle , and reverse tilt-down outside mirror angle . If they are adjusted during user registration , it may be disrupted . Refer to “ Power seat ” FP34 or “ Outside mirrors ” FP249 .
. If the ignition switch is turned to the “ OFF ” position before user registration is complete , the information of the adjusted seat position , outside mirror angle , and reverse tilt-down outside mirror angle will not be saved .
. When the user recognition setting is OFF , or when the Driver Monitoring System OFF indicator , Driver Monitoring System temporary stop indicator , or Driver Monitoring System
