382
Driver Monitoring System
& Driver Monitoring System indicator / warning
S07BP03
1 Driver Monitoring System operation indicator light ( green )
2 Driver Monitoring System OFF indicator light
3 Driver Monitoring System temporary stop indicator light
4 Driver Monitoring System warning light ( yellow )
The Driver Monitoring System indicator / warning indicates the status of the Driver Monitoring System on the combination meter display .
NOTE
When the Driver Monitoring System OFF indicator , Driver Monitoring System temporary stop indicator , or Driver Monitoring System warning is illuminated , the Driver Monitoring System function cannot be used . In addition , the following items cannot be selected .
. Register User . Delete User . Delete All Users . Update User Settings . Delete Driver Position . Automatically retract seat on entry
! Driver Monitoring System operation indicator light ( green )
S07BP0301
This indicator illuminates when the Driver Monitoring System is operating .
! Driver Monitoring System OFF indicator light
S07BP0302
This indicator illuminates when the user has pressed the Driver Monitoring System OFF switch and the Driver Monitoring System is not operating .
! Driver Monitoring System temporary stop indicator light
S07BP0303
This indicator illuminates when the Driver Monitoring System is temporarily stopped .
NOTE
The Driver Monitoring System stops temporarily in the following circumstances .
. When the temperature of the main unit of the Driver Monitoring System is high or low .
. When the Driver Monitoring System cannot monitor the driver ’ s eye movement .
. When the Driver Monitoring System cannot monitor the driver ’ s eyebrows , eyes , nose or mouth .
. When the camera and the infrared light source ( LED ) are covered and the Driver Monitoring System cannot monitor the driver correctly .
! Driver Monitoring System warning light ( yellow )
S07BP0304
This warning illuminates when there is a problem with the Driver Monitoring System . Contact a SUBARU dealer to have the system inspected .
& Using the Driver Monitoring System
S07BP04
! User recognition
S07BP0401
When a user is registered with the user recognition function , the Driver Monitoring System performs the following .
