BSD / RCTA 361 |
||||||||
|
& BSD / RCTA warning light
S07BM04
! System malfunction
S07BM0403
|
& BSD / RCTA OFF switch |
S07BM05 |
BSD / RCTA is deactivated .
Press the switch again to activate the BSD / RCTA . The BSD / RCTA OFF indicator light will disappear .
When this occurs , the BSD / RCTA approach indicator light on the side of the rearview mirror illuminates for a few seconds and then turns off .
NOTE
. In the following cases , the system may not operate properly due to blocked radar waves . Press the BSD / RCTA OFF switch to deactivate the system . – When towing a trailer – When a bicycle carrier or other carrier item is fitted to the rear of the vehicle .
– When using a chassis dynamometer or free roller device , etc .
– When running the engine and making the wheels rotate while lifting up the vehicle
. If the ignition switch is turned to the “ LOCK ”/“ OFF ” position , the last known status of the system is maintained . For example , if the ignition switch is turned to the “ LOCK ”/ “ OFF ” position with the BSD / RCTA deactivated , the BSD / RCTA will remain deactivated the next time the
|
|||||
|
1 BSD / RCTA malfunction message 2 At first , this message will appear 3 Then this message will appear 4 BSD / RCTA warning light
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
|
BSD / RCTA OFF switch
BSD / RCTA OFF indicator light
If the BSD / RCTA OFF switch is pressed , the BSD / RCTA OFF indicator light appears on the combination meter , and the
|
Starting and operating |
||||||
– CONTINUED – |
||||||||
