360
BSD / RCTA
to solid objects on the road or road side ( such as guardrails , tunnels or sidewalls ).
. The BSD / RCTA approach indicator light may flash when turning at an intersection in urban areas or a multilane intersection .
. The BSD / RCTA approach indicator light may flash and the warning buzzer may sound if a building or a wall exists in the reversing direction .
. In the following cases , the system may detect a vehicle driving two lanes away from your vehicle . – When you are driving on the near side of the lane of the corresponding vehicle .
– When the vehicle driving two lanes away is driving on the near side of its lane from your vehicle .
& BSD / RCTA OFF indicator light
S07BM08
! System temporary stop
S07BM0801
1 BSD / RCTA temporary stop message 2 BSD / RCTA OFF indicator light
This display appears when the system is used under the following conditions .
. Extremely high or low temperatures
. When abnormal voltage exists for the vehicle battery .
. When the radar sensor is significantly misaligned .
Once the above conditions are corrected , the system will recover from the temporary stop condition and the indicator will disappear . If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
! System temporary stop due to reduced radar sensitivity
S07BM0802
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator light
This display appears when the detectability of the radar sensors is reduced . Once the condition is corrected , the system will recover from the temporary stop condition and the indicator will disappear . If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
