Child restraint systems
3. Peel off the anchorage cover from the
selected side of the rear seatback. Fold the
peeled anchorage cover in half and affix it
with hook and loop tape to expose the
anchorages (bars) to be used for installa-
tion of the child restraint system.
4. Remove the rear seat head restraint.
For details, refer to “Head restraints”
FP44.
the passenger compartment, as it
could be thrown around in the
passenger compartment in a sud-
den stop or a sharp turn.
5. For models with a reclining rear seat
mechanism, adjust the seatback to the
upright position.
6. Fasten the lower hooks onto the lower
anchorages located at “ ” marks on the
bottom of the rear seatback. When the
hooks are fastened, make sure the adja-
cent seatbelts are not caught.
7. If your child restraint system is a
flexible attachment type, (which uses
tether belts).
Push the child restraint into the seat
cushion and pull both left and right lower
tether belts up to secure the child restraint
system by taking up the slack in the belt.
8. Fasten the top tether hook onto the
tether anchorage behind the rear seat and
tighten the top tether firmly. For additional
instructions, refer to “Top tether an-
chorages” FP72.
CAUTION
Store the head restraint that has
been removed in the cargo area.
Avoid placing the head restraint in
– CONTINUED –
2. There are “ ” marks at the bottom of
the rear seat seatbacks. These marks
indicate the positions of the lower an-
chorages (bars).
71
