70
Child restraint systems
There are a total of 5 lower anchorages at
the rear seat. The rear anchorage from the
right side is used for both the right seat and
center seat. Each lower anchorage is
located where the seat cushion meets
the seatback.
! Tether anchorages
S01AG070102
! To install a child restraint system
using lower and tether an-
chorages
S01AG070103
WARNING
Before installing a child restraint
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.
1. Shake the seatback slightly to confirm
that it is securely locked into place.
– Check the red colored unlocking
marker which is attached to the bottom
of the lock release knob is not visible.
For details, refer to “Folding down the
rear seatback” FP41.
This vehicle is equipped with five lower
anchorages (bars) and three upper an-
chorages (tether anchorages) for accom-
modating such child restraint systems.
! Lower anchorages
S01AG070101
The tether anchorages (upper an-
chorages) are provided at the locations
shown in the above illustration. For details,
refer to “Top tether anchorages” FP72.
