36
Seats
& Power seat (if equipped)
S01AQ06
! Driver’s seat
S01AQ0601
2)
3)
4)
5)
backward. During forward/backward ad-
justment of the seat, the seat cushion
angle or height cannot be adjusted.
Seat cushion angle control switch
To adjust the seat cushion angle, pull up
or push down the front end of the control
switch.
Seat height control switch
To adjust the seat height, pull up or push
down the rear end of the control switch.
Seatback angle (reclining) control
switch
To adjust the angle of the seatback, move
the control switch.
Lumbar support control switch
To increase lower back support, push the
front side of the switch. To decrease
lower back support, push the rear side of
the switch.
! Front passenger’s seat
S01AQ0602
1)
2)
3)
4)
1)
Seat position forward/backward con-
trol switch
To adjust the seat forward or backward,
move the control switch forward or
Seat position forward/backward con-
trol switch
To adjust the seat forward or backward,
move the control switch forward or
backward.
Seat cushion angle control switch
To adjust the seat cushion angle, pull up
or push down the front end of the control
switch.
Seat height control switch
To adjust the seat height, pull up or push
down the rear end of the control switch.
Seatback angle (reclining) control
switch
To adjust the angle of the seatback, move
the control switch.
