Starting and operating/Reverse Automatic Braking System
& Reverse Automatic Braking
System operation
When the Reverse Automatic Braking
System is in operation, the range between
the vehicle and the detected object will be
indicated on the multi function display.
Also, warning sounds will activate in 3
levels to warn the driver of a potential
collision.
Guideline of detecting range
Alert level
Range of detected object*
Long proximity (ob-
ject detected)
Distance indicator
35 inches (90 cm) or more Green
7-71
Alarm pattern
No warning sound
Medium proximity
to 35 inches (70 to 90
alert (approaching the 28
cm)
object) Yellow + Green Short beeps
Close proximity alert
(approaching closer
to the object) Orange + Yellow +
Green Rapid short beeps
Red + Orange +
Yellow + Green Continuous beep
20 to 28 inches (50 to 70
cm)
Closest proximity
alert (too close to the 20 inches (50 cm) or less
object)
*: Range of detection may vary depending on the environmental condition.
