3-34
Instruments and controls / Information display( Mexico – spec. models)
For models with type A combination meter, the BSD / RCTA warning indicator will be shown on the combination meter. For models with type B combination meter, the BSD / RCTA warning indicator will be shown on the multi information display of the combination meter.
When this indicator appears, have your vehicle inspected by your SUBARU dealer as soon as possible.
& BSD / RCTA OFF indicator( if equipped)
The indicator appears when the BSD / RCTA OFF switch is pressed to deactivate the BSD / RCTA.
For models with type A combination meter, the BSD / RCTA OFF indicator will be shown on the combination meter. For models with type B combination meter, the BSD / RCTA OFF indicator will be shown on the multi information display of the combination meter.
For details, refer to“ BSD / RCTA” F7-59.
& RAB warning light( if equipped)
This indicator illuminates if the Reverse Automatic Braking System malfunctions. Refer to“ Reverse Automatic Braking
System” F7-67.
& RAB OFF indicator light( if equipped)
This indicator illuminates when the Reverse Automatic Braking System is turned OFF, or when the Reverse Automatic Braking System is suspended temporarily. Refer to“ Reverse Automatic Braking System” F7-67.
Information display( Mexicospec. models)
NOTE
If your vehicle is equipped with a color multi function display, refer to“ Multi function display” F3-44.
1) Outside temperature indicator 2) Driving information display 3) Clock
With the ignition switch in the“ ACC” position, the clock appears on the display.
With the ignition switch in the“ ON” position, the outside temperature indicator, driving information display and clock all appear on the display.
