7-70
Starting and operating/Reverse Automatic Braking System
Guideline of detecting range
Alarm pattern
Range of detected object*
Long proximity warning (Obstacle detect
warning)
Distance indicator
35 inches (90 cm) or more Green
Warning sounds
No warning sound
Medium proximity
to 35 inches (70 to 90
warning (First braking 28
and warning - yellow) cm)
Yellow + Green
Short beeps
Short proximity warn- 20 to 28 inches (50 to 70
ing (First braking and cm)
warning - orange)
Orange + Yellow +
Green
Rapid short beeps
Closest proximity
warning (Second
20 inches (50 cm) or less
braking and warning)
Red + Orange +
Yellow + Green
Continuous beep
*: Range of detection may vary depending on the environmental condition.
Range of detected object
1) Green: 35 inches (90 cm) or more
1) Obstacle detect warning:
When an object is detected in the reversing direction, the range of detected object
will be indicated on the multi function
display.
