Starting and operating / Reverse Automatic Braking System
7-69
Parts attached to the rear bumper near the sonar sensor – Commercial electronic parts( fog light, fender pole, radio antenna) or commercial attachment parts( trailer hitch, bicycle carrier, bumper guard) are attached – Parts that emit high frequency sound, such as a horn or speaker, are attached
Vehicle conditions – The vehicle is significantly inclined – The ground clearance is significantly reduced due to the vehicle’ s loading condition, etc. – When the sonar sensor is misaligned due to a collision or an accident
Surrounding environment – A cloth banner, flag, hanging branch or railroad crossing bars are present in the reversing direction – When reversing on a gravel or grassy area – When reversing in an area where objects or walls are adjacent to the vehicle such as narrow tunnels, narrow bridges, narrow roads or
narrow garages – Wheel tracks or a hole is present in the ground of the reversing direction – When reversing over a drainage cover( grate cover)
– The path of the reversing direction is inclined such as on a steep uphill – A curb is present in the reversing direction – When reversing downhill
& Reverse Automatic Braking System operation
When the Reverse Automatic Braking System is in operation, the range between the vehicle and the detected object will be indicated on the multi function display. Also, warning sounds will activate in 3 levels to warn the driver of a potential collision.
– CONTINUED –
