FORESTER
G AUTO button (for type B only)
FULL AUTO mode operation:
When the AUTO button is pressed, the indicator light FULL AUTO on the display illuminates.
In this state, fan speed, air flow distribution, air-inlet control, and air conditioner compressor operation
are automatically controlled.
AUTO mode operation:
If you operate any of the buttons on the control panel other than the OFF button, rear window defogger
button and temperature control dial(s) during FULL AUTO mode operation, the FULL indicator light on the
control panel will turn off and AUTO will remain illuminated. You can then manually control the system as
desired using the button you operated. To change the system back to the FULL AUTO mode, press the
AUTO button.
H OFF button (for type B only)
I Defroster button (for type B only)
Press this button to turn off the climate
control system.
Press this button to defrost windshield.
J DUAL mode button (for type B only)
Press this button to separate temperature settings for the driver’s side and passenger’s side.
MAINTENANCE
To keep your vehicle in proper operating condition and to assure peak performance at all times, the
recommended maintenance service should be performed in accordance with the maintenance schedule.
Refer to the Owner’s Manual for information on maintenance items and intervals.
Also, we recommend that you check your vehicle yourself daily for more comfortable use of your vehicle.
When you are going to check your vehicle yourself, please do so in compliance with Chapter 11 in the
Owner’s Manual.
Engine compartment overview
1
1 Brake fluid reservoir / Clutch fluid
reservoir (MT)
2 Engine oil level gauge
3 Engine coolant reservoir
4 Windshield washer tank
For models with other type of engine,
refer to Owner’s Manual.
2
3
4
15
