FORESTER
Folding down
C rear seatback
Front seatbelt
E anchor height
D Seat heater
HIGH
HIGH
LOW
LOW
HIGH: Rapid heating
To raise: Slide the anchor up.
LOW: Normal heating
To fold rear seatback down,
pull release knob and fold
seatback down.
To lower: Pull the release knob
and slide the anchor down.
F Rear center seatbelt
1
2
3
4
To fasten:
1 Remove the tongue plate from the slot
To disconnect connector
from the buckle:
Insert a tongue plate or
other hard pointed object
into the slot in the buckle.
in the recess by pulling the tongue plate,
then pull out the seatbelt slowly.
2 Pass the seatbelt through the belt guide.
3 Connect webbing end to connector.
4 Fasten the seatbelt in the usual way.
See the Owner’s Manual Chapter 1 for details.
G Lower anchorages
H Top tether anchorages
Lower anchorages are
provided for installing a
child restraint system.
They are located
behind the cover of
seat back bottom. See
the Owner’s Manual
Chapter 1 for details.
Top tether anchorages
are provided for
installing child restraint
system with top tether.
They are located on
the back side of the
rear seat back. See
the Owner’s Manual
Chapter 1 for details.
11
