Climate control
& Type C
position.
& Temperature sensors
1)
2)
3)
1. Turn the airflow control dial and fan
speed control dial to “AUTO” position.
2. Set the preferred temperature using
the temperature control dial.
NOTE
3. To turn off the climate control system,
turn the fan speed control dial to the “OFF”
employs several sensors. These sensors
are delicate. If they are not treated
properly and become damaged, the system may not be able to control the interior
temperature correctly. To avoid damaging
the sensors, observe the following precautions.
– Do not subject the sensors to impact.
– Keep water away from the sensors.
– Do not cover the sensors.
The sensors are located as follows.
– Solar sensor: beside the windshield
defroster grille.
– Interior air temperature sensor: next to
the steering column.
– Outside temperature sensor: behind
the front grille.
Fan speed control dial
Airflow control dial
Temperature control dial
Each function can be individually set to
AUTO mode independently of the
others. Any function set to AUTO mode
is controlled automatically. Any function not set to AUTO mode can be
manually adjusted as desired.
4-7
1)
2)
Interior air temperature sensor
Solar sensor
The automatic climate control system
