4-4
Climate control
! Fan speed control dial
The fan operates only when the ignition
switch is turned to the “ON” position. The
fan speed control dial is used to select
four fan speeds.
! Airflow control dial
The dial has five positions that activate the
following air outlets.
(Ventilation): Instrument panel outlets
(Bi-level): Instrument panel outlets and
foot outlets
(Heat): Foot outlets, both side outlets of
the instrument panel and some through
windshield defroster outlets (A small
amount of air flows to the windshield and
both side windows to prevent fogging.)
less of the position of the air conditioner button to defog the windshield
more quickly. However the indicator on
the air conditioner button will not
illuminate. At the same time, the air
inlet selection is automatically set to
“outside air” mode.
In this state, you cannot select “recirculation” mode by manually pressing
the air inlet selection button.
Also, you cannot stop the air conditioner compressor by pressing the air
conditioner button.
ON position (Recirculation): Interior air
is recirculated inside the vehicle. Push the
air inlet selection button to the ON position. The indicator light will illuminate.
Place the air inlet selection button to the
ON position for fast cooling with the air
conditioner or when driving on a dusty
road.
: Windshield defroster outlets and both
side outlets of the instrument panel
For details, refer to “Airflow selection” F42.
When the dial is placed in the “ ” or
“ ” position, the air conditioner compressor operates automatically regard-
Push it again to turn off the air conditioner.
! Air inlet selection button
! Air conditioner button
(Heat-def): Windshield defroster outlets, foot outlets and both side outlets of
the instrument panel
NOTE
conditioner. The indicator light will illuminate.
The air conditioner operates only when
the engine is running.
Push the air conditioner button while the
fan is in operation to turn on the air
OFF position (Outside air): Outside air is
drawn into the passenger compartment.
Push the air inlet selection button again to
the OFF position. The indicator light will
turn off.
