Instruments and controls
: Coolant temperature high warning light
(if equipped)
: Charge warning light
: Oil pressure warning light
: AT OIL TEMP warning light
(AT models)
: Low tire pressure warning light
(U.S.- spec. models)
/
/
: ABS warning light
: Brake system warning light
: Low fuel warning light
: Hill start assist warning light
(MT models)
: Door open warning light
: AWD warning light (AT models)
: Vehicle Dynamics Control warning
light/Vehicle Dynamics Control operation indicator light
3-13
: Automatic headlight beam leveler
warning light (models with HID headlights)
If any lights fail to illuminate, it indicates a
burned-out bulb or a malfunction of the
corresponding system.
Consult your authorized SUBARU dealer
for repair.
& Seatbelt warning light
and chime
Your vehicle is equipped with a seatbelt
warning device at the driver’s and front
passenger’s seat, as required by current
safety standards.
With the ignition switch turned to the “ON”
position, this device reminds the driver
and front passenger to fasten their seatbelts by illuminating the warning lights in
the locations indicated in the following
illustration and sounding a chime.
Driver’s warning light (type A)
: Vehicle Dynamics Control OFF indicator light
: SPORT mode indicator light
(AT models)
Driver’s warning light (type B)
: Cruise control indicator light
SET/
: Cruise control set indicator light
– CONTINUED –
