3-12
Instruments and controls
& ECO gauge (models with type
A combination meter)
The unit displayed varies depending on
the destination.
The ECO gauge shows the difference
between the average rate of fuel consumption since the trip meter was last
reset and the current rate of fuel consumption.
The ECO gauge indicates the current fuel
efficiency as shown in the following chart.
Displayed unit
NOTE
. The ECO gauge shows only an
approximate indication.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until driving 0.6 mile (1 km).
Until that time, the ECO gauge does not
operate.
Warning and indicator lights
Several of the warning and indicator lights
illuminate momentarily and then turn off
when the ignition switch is initially turned
to the “ON” position. This permits checking the operation of the bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. For
the system check, the following lights
illuminate and turn off after several seconds or after the engine has started.
: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON /
: Front passenger’s frontal airbag
ON indicator light
/
: Front passenger’s frontal airbag
OFF indicator light
Needle pointing
“+” side
“-” side
MPG
Better
Poorer
l/100km
Poorer
Better
: CHECK ENGINE warning light/Malfunction indicator lamp
