Maintenance and service
11-51
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a
new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.
3. Remove the bulb socket from the rear
combination light assembly by turning it
counterclockwise.
4. Pull the bulb out of the bulb socket and
replace it with a new one.
5. Set the bulb socket into the rear
combination light assembly and turn it
clockwise until it locks.
& Dome light, map light, cargo
area light and door step light
CAUTION
7. Tighten the upper and lower screws.
& License plate light
When the door is opened, the map
light illuminates and becomes very
hot. When replacing the map light
bulb, close the door and be careful
not to burn yourself.
6. Put the rear combination light assembly into place while aligning the clip with
the guide on the vehicle.
1. Remove the mounting screws using a
Phillips screwdriver.
Dome light (type A)
– CONTINUED –
