Combination Meter Display( Color LCD) 185 |
|||||||
|
– While parking or driving at low speeds
– When the outside temperature changes suddenly( example: when going in and out of an underground parking area or when passing through a tunnel)
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Fahrenheit( 8F) or Celsius( 8C). For details, refer to“ General settings” FP200( 11.6-inch display models) or“ General settings” FP216( dual 7.0-inch display models).
|
! Compass( if equipped)
s03bn1203
|
The direction of the vehicle is displayed.
! Driving range on remaining fuel s03bn1204
|
NOTE
The driving range on the remaining fuel is only a guide. The indicated value may differ from the actual driving range on the remaining fuel, so you must immediately fill the tank when the low fuel warning light illuminates.
& Telltale Screen
s03bn09
|
3
Instruments and Controls
|
|||
1 Telltale screen |
|||||||
|
When the corresponding situation occurs, the following telltales will be displayed on the telltale screen.
NOTE
. When there is warning information to display, it will be displayed in five warning indicators, starting on the
|
|||||||
– CONTINUED – |
