184
Combination Meter Display( Color LCD)
& Warning Screen |
s03bn05 |
! ECO gauge |
s03bn1201 |
. After resetting the trip meter, the average rate of fuel consumption is not shown until driving for approximately 10 seconds. Until that time, the ECO gauge does not operate. |
! Clock and temperature s03bn1202
Example of warning
If there is a warning message or a maintenance notification, it will appear on combination meter display( color LCD). Take the appropriate actions based on the messages indicated.
& Meter Information Screen s03bn12
The meter information screen can be changed. For details, refer to“ General settings” FP200( 11.6-inch display models) or“ General settings” FP216( dual 7.0-inch display models).
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption.
The ECO gauge indicates the current fuel |
efficiency as shown in the following chart. |
Displayed unit |
Needle position
“+” side
“ −” side
|
MPG |
Better |
Poorer |
l / 100km |
Poorer |
Better |
NOTE
. The ECO gauge shows only an approximate indication.
This screen displays the clock and outside temperature.
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display. For details, refer to“ Clock” FP228.
. The outside temperature indicator shows the temperature in the area around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the following conditions.
