– There is a puddle of water. – There is an obstacle that is next to an object. – Going back along a wall. – The area where the road starts touching dirt and snow – When reversing on an uneven road. |
& Sonar Audible Alarm Function s07bn03
When the Reverse Automatic Braking( RAB) system is in operation, audible warning beeps will sound to warn the driver of a potential collision in 3 levels: medium proximity, short proximity, closest proximity.
NOTE
It may take time to display the wall and sound warning beeps after the object was recognized by the Sonar Audible Alarm function.
|
||
|
– A curb or step is present in the reversing direction.
– Reversing in a garage with a low ceiling or a tunnel.
– There is a patch of snow rearward.
|
. In circumstances such as the following, it may not be possible to avoid a collision even when the system operates normally. – Roads are slippery. – The tire air pressure is not correct. – The tires have become worn. – Tire chains are installed. – Tires which are not the designated size are installed. – Emergency repairs were performed using a puncture repair kit. – The suspension was modified. – Vehicle driving is unstable due to accident or malfunction. – The brake warning light is illuminated. |
7
Starting and Operating
|
|
– CONTINUED – |
