Warning and Indicator Lights
sound for 15 seconds, and it then will become louder and continue for 35 seconds. The warning light will blink for 50 seconds, then it will illuminate steadily and the chime will stop.
– The warning light will blink, and the beep will sound loudly for 35 seconds when the vehicle speed is approximately more than 13 mph( 20 km / h). After 35 seconds, the blinking warning light will illuminate steadily and the chime will stop. The warning lights will continue to illuminate until their seatbelts are fastened.
. The warning light will turn off and the warning chime will stop when the seatbelt is fastened.
& SRS Airbag System Warning Light
WARNING
s03ae02
If the warning light exhibits any of the following conditions, immediately stop the vehicle in a safe place, and consult a SUBARU dealer. Unless a technician checks and repairs the system as needed, the seatbelt pretensioners and / or the SRS airbag will not operate properly in the event of a collision, which may result in injury.
. Flashing or flickering of the warning light
. No illumination of the warning light when the ignition switch is first turned to the“ ON” position
. Continuous illumination of the warning light
. Illumination of the warning light while driving
For details about the components monitored by the warning light, refer to“ SRS Airbag System Monitors” FP100.
& Front Passenger’ s Frontal Airbag ON and OFF Indicator Lights s03ae03
: Front passenger’ s frontal airbag ON indicator light
: Front passenger’ s frontal airbag OFF indicator light
For details about the operating conditions of SRS seat cushion airbag, refer to“ SUBARU Advanced Frontal Airbag System” FP81.
The front passenger’ s frontal airbag ON and OFF indicator lights show you the status of the front passenger’ s SRS frontal airbag.
The indicators are located as shown in the illustration.
When the ignition switch is turned to the
