Warning and Indicator Lights 157 |
|||||||||
! Rear passenger ’ s seats |
Rear seatbelt warning light 1 Rear left seat 2 Rear center seat 3 Rear right seat
s03ae0115
|
With the ignition switch turned to the “ ON ” position , the seatbelt warning light and chime reminds the rear passenger to fasten their seatbelt by illuminating the warning lights in the locations indicated in the above illustration and sounding a chime .
WARNING
. The driver must check that all the passengers have fastened their seatbelts properly since the seatbelt
|
warning system may not detect passengers under the following circumstances .
– When cushions or child restraint systems , etc ., are used .
– When a child or small adult is sitting in the seat .
. Observe the following precautions
– Do not apply any strong impact to the rear seat .
– Do not fold the seatback forward when objects are on the seat .
– Do not spill liquid on the rear seat . If liquid is spilled , wipe it off immediately .
– Do not remove or disassemble the rear seat .
NOTE
. The seatbelt warning system of the rear seat detects if the seat is occupied by a passenger . Heavy cargo or large pets on the rear seat may result in the activation of the passenger seatbelt warning light and chime . Fastening the rear seatbelt prior to loading cargo or large pets will avoid activating the passenger
|
seatbelt warning light and chime .
. When folding the rear seat , ensure that the seat is empty prior to folding . Items caught between the seat bottom and seatback , when folded , may damage the seat surface or activate the passenger seatbelt warning light and chime .
If passengers in the rear seats do not fasten their seatbelts while the ignition switch is turned to the “ ON ” position , the seatbelt warning lights will illuminate or blink to indicate that their seatbelts are not fastened .
NOTE
. If the rear passenger ’ s seatbelt ( s ) are / is still not fastened while driving , the seatbelt warning system operates as follows according to the vehicle speed . – The warning light will illuminate when the vehicle speed is approximately 4 mph ( 6 km / h ) or less .
– When the vehicle speed is approximately between 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ), the seatbelt warning lights will blink and a warning chime will sound . The chime will make a beep
|
3
Instruments and Controls
|
||||
– CONTINUED – |
