272
Manual Climate Control
. The fan speed will be set on the maximum speed .
. The air inlet will be set to the recirculation mode .
. The airflow mode setting will be set to the ventilation mode .
To turn off the Max A / C mode and return to the previous setting , touch “ MAX A / C ” again .
! SYNC mode s04aj0207
When the SYNC mode is turned on , both the driver ’ s and passenger ’ s side temperatures are synchronized using the driver ’ s side temperature control button and temperature control screen .
. If “ SYNC ” is displayed on the customizable icon , touch “ SYNC ” to turn the SYNC mode on or off .
. If a customizable icon other than “ SYNC ” is displayed , touch the climate control mode indicator . Then touch “ SYNC ” to turn the SYNC mode on or off .
The SYNC mode indicator will turn white .
Touch “ SYNC ” again , press the passenger ’ s side temperature control button or operate the passenger ’ s side temperature control bar to cancel the SYNC mode . The SYNC mode indicator will be grayed out . In this case , temperature control on the driver ’ s side and passenger ’ s side will be separated . The temperature will be controlled individually using the driver ’ s and passenger ’ s temperature control button and the driver ’ s and passenger ’ s temperature control bar .
& Fan Speed Control s04aj03
Select the preferred fan speed by touching or on the climate control screen .
& Air Conditioner Control s04aj04
The air conditioner operates only when the engine is running .
Perform the following operation while the fan is in operation to turn on the air conditioner .
. If “ A / C ” is displayed on the customizable icon , touch “ A / C ”. When the air conditioner is on , the “ A / C ” indicator illuminates . And A / C icon will be displayed on the climate control mode indicator .
. If a customizable icon other than “ A / C ” is displayed , touch the climate control mode indicator . Then touch “ A / C ” on the climate control mode select icon . When the air conditioner is on , “ A / C ” indicator illuminates . And A / C icon will be displayed on the climate control mode indicator .
To turn off the air conditioner , touch “ A / C ” again . The indicator light will turn off or it will be grayed out .
NOTE
For efficient defogging or dehumidifying in cold weather , turn on the air conditioner . However , if the ambient temperature decreases to approximately 328F ( 08C ), the air conditioner and dehumidification system may not work properly .
& Air Inlet Selection s04aj05
Select the air inlet by touching the air inlet selection icon .
Recirculation mode :
Interior air is recirculated inside the vehicle . This mode is used for the following cases .
. When driving on a dusty road
. When you want cooling performance to increase ( for example , in particularly hot weather )
Perform the following operation to select this mode .
. is displayed on the customizable icon : ( 1 ) Touch .
