236
Light Control Switch
High beam assist indicator
When the high beam assist function is activated , the high beam assist indicator on the combination meter will illuminate .
NOTE
If the high beam assist function is malfunctioning or is temporarily stopped , the headlight will be fixed at low beam .
! How to temporarily lower the sensitivity of the high beam assist function s03ah0704
The sensitivity of the high beam assist function can be lowered by using the following operations .
1 . After turning the ignition switch to the “ ON ” position , set the light control switch to the “ AUTO ” position and push the signal lever forward ( high beam position ).
2 . After the high beam assist indicator on the combination meter will illuminate , turn the ignition switch to the “ OFF ” position .
3 . Turn the ignition switch to the “ ON ” position and within approximately 15 seconds , press the “ / ” ( following distance setting ) switch more than 10 times consecutively .
When the sensitivity of the high beam assist function is lowered , the high beam assist indicator light “ ” on the combination meter display ( color LCD ) will flash .
NOTE
. The sensitivity of the high beam assist function cannot be lowered in the following conditions . – Cruise control indicator is illuminated . – The EyeSight warning indicator
( yellow ) is illuminated .
. The sensitivity of the high beam assist function returns to normal level the next time the ignition switch is turned to the “ LOCK ”/ “ OFF ” position and the engine is restarted .
! How to change the headlight mode manually s03ah0702
Change to the low beam : . Set the light control switch to “ ”.
. Pull the lever while the high beam is turning on and release it .
Change to the high beam : Push the lever forward and release it .
At this time , the high beam assist function will turn off , the high beam assist indicator will turn off and the high beam indicator light will turn on .
NOTE
. After manually changing the headlight mode to the high beam , if you turn on the high beam assist function , push the lever forward and release it .
. When manually changing the headlight mode to the high beam , if you turn the light control switch to the “ ” position , the parking lights , front side marker lights , rear side marker lights , tail lights and license plate lights will turn on .
