Seat , seatbelt and SRS airbags / SRS airbag ( Supplemental Restraint System airbag ) 1-51
11 ) Seatbelt pretensioner ( driver ’ s side )
12 ) Seatbelt pretensioner and adaptive force limiter ( front passenger ’ s side )
13 ) Curtain airbag sensor ( rear wheel house right-hand side )
14 ) Curtain airbag sensor ( rear wheel house left-hand side )
15 ) Curtain airbag module ( right-hand side ) 16 ) Curtain airbag module ( left-hand side ) 17 ) Seatbelt buckle switch ( front passenger ’ s side )
18 ) Knee airbag module ( driver ’ s side )
19 ) Front passenger ’ s occupant detection system sensors
20 ) Front passenger ’ s occupant detection control module
21 ) Front passenger ’ s frontal airbag ON and OFF indicator
22 ) SRS airbag system warning light 23 ) Satellite safing sensor ( under the rear center seat )
24 ) Front door impact sensor ( left-hand side )
25 ) Front door impact sensor ( right-hand side )
26 ) Lap belt pretensioner ( front passenger ’ s side )
1 ) |
Airbag control module ( including impact |
sensor and rollover sensor ) |
2 ) |
Frontal airbag module ( driver ’ s side ) |
3 ) |
Frontal airbag module ( front passenger ’ s |
side ) |
4 ) |
Front sub sensor ( left-hand side ) |
5 ) |
Front sub sensor ( right-hand side ) |
6 ) Side airbag module ( driver ’ s side )
7 ) Side airbag module ( front passenger ’ s side )
8 ) Side airbag sensor ( center pillar left-hand side )
9 ) Side airbag sensor ( center pillar righthand side )
10 ) Airbag wiring
– CONTINUED –
