Seat , seatbelt and SRS airbags / SRS airbag ( Supplemental Restraint System airbag ) 1-65
! In cases of rollover accident or side collisions , the following components will operate simultaneously
S01AH0306
Impact sensors affected
Both of the sensors together sense an impact force
Both of the sensors together sense an impact force
Both of the sensors together sense an impact force
Impact sensor in front doors
Impact sensor under rear center seat
Impact sensor in center pillars
Impact sensor under rear center seat
Impact sensor in rear wheel houses
Impact sensor under rear center seat
Rollover sensor in airbag control module
Impacted side
SRS side airbags Non-impacted side
SRS curtain airbags
Impacted side
Non-impacted side
Seatbelt pretensioner ( shoulder belt pretensioner only )
Impacted side
Non-impacted side
* — * — * —
* — * — — —
— — * — — —
— — * * * *
*: Activated —: Not activated
– CONTINUED –
