Seat , seatbelt and SRS airbags / SRS airbag ( Supplemental Restraint System airbag )
for front seat occupants . ! SRS curtain airbag
S01AH0303
Your vehicle is equipped with a SUBARU SRS curtain airbag system that complies with the Federal Motor Vehicle Safety Standard ( FMVSS ) No . 226 .
The SRS curtain airbag on each side of the cabin is stored in the roof side ( between the front pillar and a point over the rear seat ). An “ SRS AIRBAG ” mark is located at the top of each center pillar .
In a moderate to severe side impact collision , the SRS curtain airbag on the impacted side of the vehicle deploys between the occupant and the side window and supplements the seatbelt by reducing the impact on the occupant ’ s head .
In a rollover , SRS curtain airbags on both sides of the vehicle deploy between the occupant and the side window and supplement the seatbelt by reducing the impact to the occupant ’ s head .
In an offset frontal collision , SRS curtain airbags on both sides of the vehicle deploy between the occupant and the side window and supplement the seatbelt by reducing the impact to the occupant ’ s head and chest .
! Operation
S01AH0301
The SRS side airbag and SRS curtain airbag can function only when the ignition switch is in the “ ON ” position .
The following airbags deploy independently of each other since each has its own impact sensor .
. Driver ’ s SRS side airbag . Front passenger ’ s SRS side airbag . SRS curtain airbag ( right-hand side ) . SRS curtain airbag ( left-hand side )
Therefore , they may not both deploy in the same accident . Also , the SRS side airbag and SRS curtain airbag deploys independently of the driver ’ s and front passenger ’ s SRS frontal airbags in the steering wheel and instrument panel .
An impact sensor , which senses impact force , is located in each of the following locations .
. In the left and right front doors . In the left and right center pillars . In the left and right rear wheel houses . Under the rear center seat
A rollover sensor is also located inside the airbag control module .
