About EyeSight
X-MODE indicator
This indicator illuminates when the X-MODE is on.
� Refer to the vehicle Owner’s Manual for details.
Lane Departure Warning OFF indicator light
• This indicator light illuminates when the Lane Departure Warning and
Lane Sway Warning are off.
• It also illuminates when the ignition switch is turned to the ON position.
Approximately 7 seconds after the engine starts, the Lane Departure
Warning OFF indicator light will turn off or remain illuminated depending
on the current status (ON or OFF).
� Page 97
Pre-Collision Braking System OFF indicator light
• This indicator light illuminates when the Pre-Collision Braking System
and Pre-Collision Throttle Management are off.
• It also illuminates when the ignition switch is turned to the ON position,
and then turns off approximately 7 seconds after the engine starts.
� Page 41
Lane indicator
This indicator illuminates in gray when the (Lane Keep Assist)
switch is pressed.
• Both right and left lines or only one line illuminates in blue when Lane
Centering Function is active.
• Both right and left lines illuminate in white when the Lane Departure
Prevention Function is standby or active.
• If your vehicle is about to drift out of the lane while Lane Centering
Function is active, the line the vehicle is about to cross will blink in yellow.
� Page 85
Lane Centering lead vehicle indicator
Lane Centering Function is operating by detecting the lead vehicle.
19
