Starting and operating/BSD/RCTA
appear. If the indicator remains displayed
for a prolonged time, have the system
inspected at a SUBARU dealer.
! System temporary stops due to
reduced radar sensitivity
& BSD/RCTA warning indicator
7-59
& BSD/RCTA OFF switch
S07BM04
S07BM05
! System malfunction
S07BM0403
S07BM0802
BSD/RCTA OFF switch
1)
2)
BSD/RCTA temporary stop message due
to reduced radar sensitivity
BSD/RCTA OFF indicator
This display appears when the detectabil-
ity of the radar sensors is reduced. Once
the condition is corrected, the system will
recover from the temporary stop condition
and the indicator will disappear. If the
indicator remains displayed for a pro-
longed time, have the system inspected
at a SUBARU dealer.
1)
2)
3)
4)
BSD/RCTA malfunction message
At first, this message will appear
Then this message will appear
BSD/RCTA warning indicator
This display appears when a malfunction
occurs in the system. Contact a SUBARU
dealer and have the system inspected.
BSD/RCTA OFF indicator (type A)
– CONTINUED –
