Keys and doors / Alarm system 2-25
& Alarm system operation
S02AF01
When the alarm system is armed, it is triggered by opening any of the doors, rear gate or engine hood.
The alarm system will activate the following alarms when triggered.
. The vehicle’ s horn will sound for 30 seconds.
. The hazard warning flashers will flash for 30 seconds.
If any of the doors, rear gate or engine hood remains open after the 30-second period, the horn will continue to sound for a maximum of 3 minutes. If the door, rear gate or engine hood is closed while the horn is sounding, the horn will stop sounding with a delay of up to 30 seconds.
NOTE
The alarm system can be set to trigger the illumination of the following interior lights.
. Map lights( illuminates only when the door interlock switch is in the“ DOOR” position). Dome light( illuminates only when the dome light switch is in the“ DOOR” position). Cargo area light( illuminates only when the cargo area light switch is in the“ DOOR” position)
The notifications regarding the map lights, dome light and cargo area light are deactivated as the factory setting. A SUBARU dealer can activate the system. Contact your SUBARU dealer for details.
& Arming the system
S02AF04
The alarm system becomes armed when the following operation is performed.
1. Close all windows and the moonroof( if equipped) and turn the ignition switch to the“ OFF” position.
2. Carry the key and get out of the vehicle.
3. Make sure that the engine hood is closed.
4. Lock the doors using any of the following methods.. Locking using the remote keyless entry system. For details, refer to“ Remote keyless entry system” ☞2-17.. Locking using the keyless access function( if equipped). For details, refer to“ Locking with the door lock sensor” ☞2-8.. Locking using the power door locking switch. For details, refer to“ Locking using power door locking switch” ☞2- 22.
NOTE
Security indicator light
. All doors and the rear gate will lock, an electronic chirp will sound once, the hazard warning flashers will flash once, and the security indicator light will start flashing rapidly.. If any of the doors or the rear gate is not fully closed, an electronic chirp sounds five times, the hazard warning flashers flash five times to alert you that the doors( or the rear gate) are not properly closed. When you close the door, doors will automatically lock.
5. Approximately 30 seconds later, the system will enter surveillance state.
– CONTINUED –
