About EyeSight
■ EyeSight temporary stop indicator (white)
x This indicator illuminates when the EyeSight system is temporarily stopped.
x When the ignition switch is placed in the ON position, it will illuminate if the
(CRUISE) switch or
(Lane Keep Assist) switch is set to ON within approximately 7
seconds of the engine starting. It turns off when approximately 7 seconds have elapsed
since the engine started.
x When it is illuminated, none of the EyeSight functions can be used except for Conven-
tional Cruise Control.
Refer to page 89.
■ X-mode indicator
The X-mode indicator
illuminates when the X-mode is ON.
■ Lane Departure Warning OFF indicator light
x This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are
off.
x It also illuminates when the ignition switch is turned to the ON position. Approximately 7
seconds after the engine starts, the Lane Departure Warning OFF indicator light will turn
off or remain illuminated depending on the current status (ON or OFF).
Refer to page 70.
■ Pre-Collision Braking System OFF indicator light
x Illuminates when the Pre-Collision Braking System and Pre-Collision Throttle Manage-
ment are off.
x It also illuminates when the ignition switch is turned to the ON position, and then turns off
approximately 7 seconds after the engine starts.
Refer to page 33.
■ Lane Indicator
This indicator illuminates in gray when the Lane Keep Assist switch is pressed. When the
Lane Keep Assist is operational or operating, this indicator illuminates in white.
Refer to page 58.
15
