3-10
Instruments and controls/Meters and gauges
& Double trip meter
! Type B combination meter
Perform the procedures described in
“Gauge Initial Movement” F3-41.
& Speedometer
The speedometer shows the vehicle
speed.
& Odometer
Type B
1) Trip knob (U.S.-spec. models)
2) Trip knob (except U.S.-spec. models)
Type A
1) Trip knob
This meter displays the odometer when
the ignition switch is in the “ON” position.
The odometer shows the total distance
that the vehicle has been driven.
Type A
1) Trip knob
If you press the trip knob when the ignition
switch is in the “LOCK”/“OFF” or “ACC”
position, the odometer/trip meter will light
up. If you do not press the trip knob within
10 seconds of illumination of the odometer/trip meter, the odometer/trip meter
will turn off.
Also, if you open and close the driver’s
door within 10 seconds of illumination of
the odometer/trip meter, the odometer/trip
meter will turn off.
Type B
1) Trip knob (U.S.-spec. models)
2) Trip knob (except U.S.-spec. models)
