Specifications/Fuses and circuits

Fuse
panel

Fuse
rating

15

10A

.
.

16

7.5A

17

15A

18
19
20

Fuse
panel

Fuse
rating

Luggage light
Clock

32

7.5A

.

Steering
unit

.

Illumination

33

7.5A

.

.

Seat heaters

Vehicle Dynamics Control unit

10A

.

Backup light

7.5A

.
.

Power window relay
Radiator main fan relay

10A

.

Accessory power outlet
(instrument panel)

21

10A

.

Starter relay

22

7.5A

.
.

Air conditioner
Rear window defogger
relay coil

23

Empty

24

10A

.
.

Audio unit
Clock

25

15A

.

SRS airbag system

26

Empty

27

15A

.

Blower fan

28

15A

.

Blower fan

29

15A

.

Fog light

30

Empty

31

7.5A

.
.

Auto air conditioner unit
Integrated unit

Circuit

12-11

Circuit
lock

control

– CONTINUED –
