Starting and operating/Continuously variable transmission
performing the above procedure, perform
the following steps.
. When the select lever cannot be
shifted from “P” to “N”:
Refer to “Shift lock release using the shift
lock release button” F7-19.
. When the select lever cannot be
shifted from “N” to “R”, “P”:
Within 60 seconds after placing the ignition switch in the “ACC” position, move the
select lever to the “P” position with the
select lever button pressed and brake
pedal depressed.
If you must perform the above procedure,
the shift lock system (or the vehicle control
system) may be malfunctioning. Contact a
SUBARU dealer for an inspection as soon
as possible.
7-19
insert a screwdriver into the hole, press
the shift lock release button using a
screwdriver, and then move the select
lever.
If the select lever does not move after
performing the above procedure, the shift
lock system may be malfunctioning. Contact a SUBARU dealer for an inspection
as soon as possible.
& Driving tips
2. Wrap the tip of a flat-head screwdriver
with vinyl tape or a cloth and use it to
remove the shift lock cover. The shift lock
release button is located under the shift
lock cover.
If the select lever does not move after
performing the above procedure, refer to
“Shift lock release using the shift lock
release button” F7-19.
! Shift lock release using the shift
lock release button
Perfo
