Instruments and controls/Multi function display
& Basic screens
3-47
! Information bar
! Basic screen items
These are the basic screens of the multi
function display.
Item
Page
Information bar
3-47
Fuel consumption screen
3-48
ECO history screen
3-49
Vehicle activation status
screen
3-50
EyeSight screen (models with
the EyeSight system)
3-51
Triple meter screen
3-51
Icy road surface warning screen
Guidance screen
3-52
Clock/calendar screen
3-52
By operating the “ ” or “ ” switch on the
steering wheel, you can switch the screen
that is always displayed. Also, when the
button is pressed and held, the
selection screen can be displayed. For
details about the selection screen, refer to
“Selection screen” F3-54.
1)
2)
3)
4)
Information bar
Outside temperature indicator
Top display
Clock
While the ignition switch is in the “ACC” or
“ON” position, the outside temperature
indicator, clock, etc. will be shown on the
information bar.
! Outside temperature indicator
This displays the outside temperature
between −408F (−408C) and 1228F
(508C).
When the outside temperature becomes
378F (38C) or less, the icy road surface
warning screen interrupts to inform the
driver that the road surface may be frozen.
NOTE
. The outside temperature indicator
shows the temperature around the
sensor. Therefore, the temperature indication may differ from the actual
outside air temperature.
. The icy road surface warning screen
should be treated only as a guide. Be
sure to check the condition of the road
surface before driving.
. Once the icy road surface warning
screen is displayed, it will not be
displayed again unless the outside
– CONTINUED –
