Instruments and controls/Warning and indicator lights
& Hybrid Fail Lamp
The Hybrid Fail Lamp illuminates when a
malfunction occurs in the hybrid system.
CAUTION
When the Hybrid Fail Lamp is illuminated, an interruption screen will
be displayed simultaneously on the
multi function display. Perform the
procedure shown on the multi function display, then have your vehicle
inspected by a SUBARU dealer immediately.
& Pedestrian alert warning light
This light illuminates when a malfunction
occurs in the pedestrian alert system.
3-31
has been started, have your vehicle
checked at a SUBARU dealer.
& EV (Electric Vehicle)
mode lamp
This light illuminates in the following
cases.
. When driving only using the electric
motor power
. When the engine is automatically
stopped by the hybrid system
! Activation/deactivation settings
The EV (Electric Vehicle) mode lamp can
be activated or deactivated. To change the
setting, perform the following procedure.
1. Turn the ignition switch to the “LOCK”
or “ACC” position.
2. Press the trip knob to show “
“
” on the trip meter display.
” or
The display can be switched as shown in
the following sequence by pressing the
trip knob.
& Hybrid READY Indicator Light
This light illuminates when the hybrid
system has started. It turns off when the
hybrid system has been turned off.
CAUTION
If the Hybrid READY Indicator Light
does not illuminate when the engine
– CONTINUED –
